2500 x 1600 mm Fast & Precise Mold-Free CNC Gasket Cutting Machine with Auto Feeding

2500 x 1600 mm Fast & Precise Mold-Free CNC Gasket Cutting Machine with Auto Feeding

Brand Name:	IBON
Model Number:	IB2516
MOQ:	1
Payment Terms:	,T/T,Western Union,MoneyGram
Supply Ability:	300 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

DongGuan, China

Product Name:

CNC Sheet Cutting Machine

Size:

2500 X 1600 Mm

Customization::

Available

After-sales Service::

Three Year Warranty

Warranty::

Lifetime Free Upgrade Lifelong Free Service

Cutting Materials::

Gasket,PVC,EPE,Rubber,Foam,Sponge,Carbon Fiber,Composite Material.,etc.

Packaging Details:

Wooden Case

Highlight:

Punch Gasket Cutting Machine

Shoe Manufacturing Gasket Cutting Machine

Product Description

2500 x 1600 mm Fast & Precise CNC Gasket Cutting Machine

The IBON CNC oscillating knife cutting machine features a high-frequency pneumatic oscillation tool for precision gasket cutting. With advanced mechanical design and professional sealing industry software, this mold-free industrial cutter delivers high precision, speed, and quality for sealing applications.

Product Specifications

Model	IB1625
Certification	CE, ISO 9001:2000
Working Area	1600 * 2500 mm
Cutting Accuracy	0.05 mm
Cutting Speed	0-1800 mm/s
Cutting Thickness	0-50 mm (material dependent)
Rated Power	11 kW
Rated Voltage	220V or 380V 3 Phase
Control System	LCD Touch Screen
Weight	1240 kg
Applications	Paper, Plastic, Leather, Fabric, Carbon Fiber, Prepreg, Foam, Rubber

Key Advantages

Environmental protection - no smoke or odor emissions
High efficiency - cutting speeds up to 1500 mm/s, reducing labor costs
Superior finish - no yellow edges or rough selvedge after cutting
Multifunctional cutting - supports complex and irregular shapes
Wide application range - automotive interiors, advertising, furniture, leather, and clothing industries

Main Components

Oscillating Knife Tools

Designed for softer, medium-density materials with high oscillating frequency enabling fast processing speeds and greater throughput.

Automatic Loading Platform

Infrared sensing adjusts platform height, while feeding suckers transport materials to the worktable automatically.

Ruida Controller

Supports USB computer control and offline operation via U disk, featuring high voltage resistance and antistatic protection.

Delta Servo Motor

Provides faster speed with signal feedback, low heat radiation, smooth ultra-low speed operation, and reduced vibration.

Aluminum Vacuum Table

Strong suction minimizes material movement, enhancing precision for intricate designs and complex shapes in high-speed cutting applications.

Infrared Safety Sensor

Detects obstacles and immediately halts operation to protect operators and prevent machine damage.

Cost Savings & Productivity Benefits

Eliminate Mold Costs

No development, storage, maintenance, or replacement required. Annual savings: $10,000 - $200,000 depending on product variety.

Material Optimization

Auto-nesting reduces waste by 30-50%, especially beneficial for rubber, graphite, and PTFE materials.

Production Speed Increase

5-10* faster than manual cutting and 3-5* faster than die cutting for multi-shape orders.

Quality Consistency

Digital cutting ensures identical sizing, consistent tolerances, and zero error rates across all production runs.
